ADL 3100 Series Auto Download | Profits On Hold Products
ADL 3100 Series Auto Download
The Ultimate in Information On-Hold
Project a big image from your home office!
The 3100 is solid state with a built-in tape player that downloads prerecorded tapes into the digital electronics for the playing of quality trouble-free messages On-Hold.
Features
Technical Specifications
Installation/Connections
Features
Flash Memory – A technological breakthrough gives the 3100 the memory of the future. This new, nonvolatile memory means the recording will never be lost due to loss of power.
Tape Mechanism – To guarantee a perfect download, our system uses the highest quality tape drive in the industry. This drive is built to accompany high end stereo equipment, not the lower quality tape drives found in answering machines. The unit loads your customized On-Hold program on speed every time.
Crystal-Clear Sound Quality – 64 kbps sampling assures the highest quality playback of your on-hold message.
Zero Gap – Most auto download systems listen for silence to know when to stop recording. It hears a predetermined length of silence and stop recording. This leaves an irritating gap of silence between the end of your production and the beginning. Our system is different. It records the silence gap, but the on-board computer has the intelligence to go back and delete the silence, leaving ZERO GAP in the loop.
Verbal Prompting – Our unit is easy to operate. A human voice leads you through installation of the production. When power is supplied to the system it says, “Please insert your cassette tape with the label facing you and close my door.” When this is done you will hear, “I am loading your production now.” At the end of the downloading the machine lets you know everything is okay by saying, “I have successfully digitized your tape.”
Tone Control – The new tone control gives a wider range of sound to the telephone system.
Technical Specifications
Sample Rate:
64 kbps (effective 96 kbps).
Recording Time:
2 minutes up to 47 minutes (model dependent).
Frequency Response:
200 Hz to 3400 Hz + or – 1 dB (full spectrum of telephone transmission)
Flash Memory:
Nonvolatile, unaffected by power interruptions, no matter how long the unit is without power.
Power Source:
12V AC adaptor, included.
Audio Output:
600 Ohm and 8 Ohm (Note: 8 Ohm output has a 5-watt amplifier.)
Tone Control: :
Controls the tone on the 8 Ohm and 600
Verbal Prompting:
Assists with loading of the production.
Dimensions:
5.25″H x 8.5’W x 5″D
Weight:
6 lb (Boxed)
Installation/Connections
Plug the small-connector end of the AC adapter into the 12 VDC Input jack at the side of the unit. Plug the larger, power supply end of the adapter into a grounded AC power outlet. The AC outlet should be the one that remains on at all times.
Connect a cable (provided) from the music On-Hold input of the telephone system to the 600 or 8 Ohm Output jack of the unit.
To download production, press the EJECT button on face of the 3100 to open cassette door. Built-in voice recording will guide you through loading of production.
Adjust volume as needed.
ADL 3100 Series Auto Download
Warranty
Upon receipt, the manufacturer will repair or replace, at its option, for a period of three years from the date of installation, any system that proves defective in materials or workmanship. The manufacturer is not liable for indirect, incidental, or consequential damages in connection with the use of this product. This limited warranty does not include labor for installation or removal of unit.
FCC
FCC Information
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against interference when the equipment is operated in a commercial environment. The user is cautioned that changes or modifications that are not expressly approved by Profits On-Hold Productions, LLC could void the user’s authority to operate the equipment.
